This is an Intelligent Display Solutions 2x16 COG alphanumeric red on black LCD display module. Its part number is CI064-4001-38. This LCD display has 2 rows of 16 characters. It offers a low cost, low energy and simple method to add a display to your design. The IDS board enables the displays to be used with the industry standard 16-pin interface. It is new and has never been used. It was originally bulk packaged and we have repackaged it for individual sale. It comes as pictured and does not include any additional parts or accessories.

Specifications:

• Manufacturer: Intelligent Display Solutions
• Part Number: CI064-4001-38
• External Height: 7.9mm
• External Depth: 27.5mm
• External Width: 76mm
• Viewing Area Dimensions: 63.5 x 16.5mm
• Character Height: 5.6mm
• Character Width: 3mm
• Character Rows: 2
• Operating Temperature Range: -20 - 70°C
• Background Color: Black
• Interface Type: 4-Bit MPU, 8-Bit MPU
• Display Mode: Transmissive
• Characters per Row:16
• Character Matrix: 2 Rows by 16 Characters
• Illumination Color: Red
• Driver Mounting: COG
• Display Type: Alphanumeric
• Backlight Type: LED
• Current Rating: 2mA
• Voltage Rating: 2.7 → 5.5V
